Dimensions
- 135mm wide;
- weight: 283g;
- 5mm QR but 10mm end caps;
- 8/9/10 speed freehub.
Wheel building data
| Dimension | mm |
|---|
| WL, width from center to left flange | 35.0 |
|---|
| WR, width from center to right flange | 22.0 |
|---|
| dL, left flange diameter | 58.0 |
|---|
| dR, right flange diameter | 49.0 |
|---|
| S, spoke hole diameter | 2.4 |
|---|
Spoke lengths for Novatec 712 and 26" Crest rim
I used this hub for a rear wheel build using a Crest 26" rim. Spoke lengths used were 262mm both sides laced 3x. If you wanted to use a different number of crosses with a Crest 26" rim then:
| cross | left length (mm)
| right length (mm)
|
|---|
| 0 | 244.3 | 247.3 |
|---|
| 1 | 246.7 | 249.3 |
|---|
| 2 | 253.5 | 255.0 |
|---|
| 3 | 263.4 | 263.3 |
|---|
| 4 | 274.6 | 272.8 |
|---|
Spoke lengths for Novatec 712 and 27.5"/650B Crest rim
Based on measured ERD of 568mm:
| cross | left length (mm)
| right length (mm)
|
|---|
| 0 | 256.2 | 259.2 |
|---|
| 1 | 258.6 | 261.3 |
|---|
| 2 | 265.4 | 266.9 |
|---|
| 3 | 275.2 | 275.2 |
|---|
| 4 | 286.4 | 284.7 |
|---|
Spoke lengths for Novatec 712 and 29" Crest rim
Based on measured ERD of 608mm:
| cross | left length (mm)
| right length (mm)
|
|---|
| 0 | 276.0 | 279.2 |
|---|
| 1 | 278.4 | 281.2 |
|---|
| 2 | 285.2 | 286.8 |
|---|
| 3 | 295.0 | 295.1 |
|---|
| 4 | 306.2 | 304.6 |
|---|
